MDPL-MTC-14B Granite Multi Cutter Machine 9 Blades

The MDPL-MTC is a multi-blade block saw designed to cut stone blocks into slabs of varying thickness with precision and efficiency. Equipped with up to 14 blades and an innovative screw-type up-down mechanism, it significantly reduces cutting time, enhancing productivity and output.

  • Time Saving in Up – Down Screw Type
  • Accurate slab thickness by Encoder
  • Robust structure with reinforced concrete for stable cutting.
  • Less Energy consumption
  • Roller LM Bearing for smooth motion.
  • PLC control system and friendly human machine interface via LCD to achieve computerized control.
  • Precise movement of cutting head in horizontal direction by precision rack & gear

Particular Unit Value
Beam Length Meter 9
Blade Motor Power HP 120
Bridge Up-down Motor Power HP 5
Cross Travel Motor Power HP 7.5
Up – Down Movement is Screw Type
Chrome Pipe Length MM 2000
Cutter Guard is SS Sheet Type Front PVC Sheet
Bellow for Beam Type Cloth
Spindle Housing Single RPM Type
Blade Cross Movement MM 6900
Blade Vertical Movement MM 700
Maximum Blade Diameter MM 2450
Spindle Diameter MM 160
Cutting Rough Block (Length) Feet 13’-0”
Cutting Rough Block (Width) Feet 8’-0”
Cutting Rough Block (Height) Feet 3’-9”
Maximum Cutting Depth in Slab MM 1050
Maximum Flange Diameter MM 300
Working Trolley (Length) Feet 10’-0”
Working Trolley (Width) Feet 6’-0”
Loading Trolley (2 Nos.) Wheel Type V – Type
V – Rail Line with Machine Feet 20’ x 2
PLC Control Panel with Loom Siemens Panel to Machine
